oh i think i’ve found it, those unexpected arguments are variables set by the other example, they’re not listed here https://registry.terraform.io/providers/hashicorp/aws/latest/docs/resources/db_instance

oh, that template is also using aws_db_parameter_group, that’s where those attrs come from

@Paulo Castro this is better in #pr-reviews

I will try to find out more about the BridgeCrew step

We ended up doing something similar to this using a TFE workspace to manage other TFE workspaces. We look at a yaml file to set the unique variables on the workspace (and any workspace specific settings).

Alternatively you could do it in one big state, but that’s not great.

Great! Thanks for helping

Is there a concern for blast radius by doing it this way? Won’t the state file be unnecessarily large if and when you end up with 100’s and 1000’s of workspaces where it’s all essentially in a single state file? (Under the workspace that’s managing all the other workspaces). Is there a way to split this up?

I’m pretty sure the module is only downloaded once. There are just two copies on the filesystem

also maybe post in #terragrunt

Hrmmmmm so since the modules use null-label the names of all resources should be easily disambiguated. Are you naming each instance differently?

Yep it does seem unsupported

https://github.com/cloudposse/terraform-aws-waf/blob/cc930d80a0d388cf503426014b6f855e879ff129/rules.tf#L136

The way to have it setup, you have the rule (1), then statement (2), then “and statement” (3), then the byte statement match (4) and the module doesn’t allow the level 3 portion of the “and statement”

@Tomer we’re always looking for contributors and ways to improve our modules. Would you be willing to write up a ticket or contribute this feature?

Would love to!

Unsure I will be able to contribute the feature, but I could at least make the feature request and maybe even start something for discussion and consideration

IMO, because of the insanity of aws_wafv2_webacl’s resource schema, all modules implementing it are really ugly and require you to write in a module-specific format to create the correct resource-specific schema which then doesn’t exactly match the AWS-level representation anyway.

It’s simpler to manage WAFv2 without a module, because as soon as your needs grow beyond the module there’s a painful ejection phase. And ultimately, WAF modules don’t have too many convenience features.

This is most certainly true… The issue comes in when we want to start doing funky loops over local values and creating similar WAF for each… it tends to turn into a looping nightmare where each connected resource must reference other resources by index or key. Kind of a rick and hard place scenario

This need in the AWS WAF resource definition to nest not_, or_ or and_ statements within other statement blocks really throws a spanner in the works and seems arbitrarily complex

I smell a feature request to AWS provider

I’m asking this because I’m creating a private cluster, inside a private subnets, and I want to only allow HTTP traffic to a very specific port, and not opening the whole cluster to the internet.

If you agree that this should be configurable, I’m happy to send a PR adding this ability

you can move the resource from the old resource to the new resource to prevent the recreation

Not sure what you mean. Can you plz elaborate.

create a data block for aws_caller_identity and output the whole thing to see all the attributes?

Where are you running Terraform? EC2 - ECS - CodeBuild also what is ~/.aws/config?

running terragrunt inside an Atlantis pod on EKS

Your EKS pod probably needs an IRSA which can assume role_arn

https://docs.aws.amazon.com/eks/latest/userguide/iam-roles-for-service-accounts.html

yeah it has it

but it couldn’t see the state bucket

figured it out

https://sweetops.slack.com/archives/CB6GHNLG0/p1657972002066169

It’s different. You may use the AWS provider for resources, but have an entirely different remote state backend. So they don’t share that configuration

https://www.terraform.io/language/settings/backends/s3#assume-role-configuration

even if I reduce it down to only 2 instances, one for each region that is aliased… It errors out on the second. I don’t encounter this same issue when using the security-group module to generate SGs in both regions. The error is on the data resource lookup for “aws_ami.info” as if it’s ignoring the provider supplied to the module. I’ve tried using both 0.41.0 and 0.43.0

There’s very strange. Could you post the hcl in an issue in the upstream module? Perhaps it’s a bug with the module or the aws provider

I think I may have got it resolved… I’d seen one issue on GitHub that didn’t have much details. It looked like I may have gotten variables crossed and passed the AMI ID for the wrong region

I’ve seen the same issue before and did not know how to track it down

Have you tried going through these troubleshooting steps?

https://aws.amazon.com/premiumsupport/knowledge-center/troubleshoot-aws-cli-commands-ec2/

Also there were issues yesterday with aws sso and today with iam. Even tho iam is global its all in the region us-east-1. So it’s possible this issue may resolve itself

yeah I tried those, and didn’t help much tbh. I’ve been having this for some time, but only now decided to get to the bottom of it

for posterity: I think I found what causes this: if the http_token in the metadata_options of the ec2_instance resource is set to “required” AND you have awscli version 1 on your instance, the temporary credentials will not be returned (awscli will return 401 for the /latest/meta-data/iam/security-credentials/ request) .

As per the documentation when it’s set to “optional” and the request has no token, it returns v1 credentials, but when “required” it returns v2 always.

https://docs.aws.amazon.com/cli/latest/reference/ec2/modify-instance-metadata-options.html

So either setting the http_token to optional, or updating the awscli to version 2 on the ami fixes this.

Ah that’s very good to know. It’s probably much easier to upgrade awscli to v2, no?

yeah, probaly that’s the way to go

I use AWS chatbot to send messages from Codepipeline to Slack using an SNS topic. Easy to set up and integrates smoothly with the rest of AWS, maybe that might be useful to you.

Ah, that’s a good idea. We do have a couple of users with slack, however the company uses teams, so we need to cover teams also, ideally.

@András Sándor that’s pretty cool. Do you use a terraform module to set that up? Is it public? I’ve been meaning to try out aws chatbot. I’d love to hear more about your set up

@Neil Caldwell there is this module that can help with setting up lambdas

https://github.com/cloudposse/terraform-aws-lambda-function

I think I set it up from the console, that was before I started replacing everything with terraform. It’s pretty much 4 resources: Chatbot, SNS Topic, and an IAM policy for each. But now that I checked it seems that TF doesn’t support Chatbot as a resource, and every chatbot TF module out there are just a Cloudformation stacks created with TF.

Havent used teams unfortunately, so have little idea for that.

ok, posting my own solution here: it worked by using length(regexall("${group}", role)) > 0] instead of the regex function.

@Jeremy G (Cloud Posse)

@Sebastian Macarescu Thank you very much for this PR.

My apologies if I said something misleading, but I really want to avoid using remote state in this module. My hope was that the kubernetes_config_map_v1_data resource would remove the need for referencing remote state by merging the EKS created roles with the customer roles.

Please elaborate on your experience with how kubernetes_config_map_v1_data works and fails to work in this scenario.

On short the kubernetes_config_map_v1_data does what it is supposed to do: setup field ownership. In official k8s documentation: https://kubernetes.io/docs/reference/using-api/server-side-apply/#merge-strategy there is a list merge functionality but the code for kubernetes_config_map_v1_data does not use that. Therefore the ownership is set on the list level not on individual items. In this case we can even remove kubernetes_config_map_v1_data since it does not fix our issue.

I can provide some examples on how the aws auth config map looks like on specific stages but on short it’s like this:

• on eks creation it contains only map_aditional_iam_roles - ownership is set to terraform • when you create eks managed node groups, it will contain the initial iam roles from the eks module plus the aws created iam roles - ownership is set to lambda • when you update the map_aditional_iam_roles and apply again it will fail because the lambda is the sole owner of the iam roles fiels in the config map. If you force the apply then it will remove the roles added by aws and reset ownership to terraform

So there is no any other way to achieve this without the self reference

OK, if we need the self-reference, then I do not think the switch to kubernetes_config_map_v1_data is worth the migration/maintenance effort. You can see how we handle this for our clients here .

I agree with this. I will remove it from the PR and push the new code

@Sebastian Macarescu We are not going to accept a PR that uses remote state because there are too many different places to store remote state. We want to leave that management to the component using the module. What you could do that would be helpful is create an example in the examples/ directory that shows how to use remote state in the component to manage the roles in the auth map. Remember, we have an example of how to do that here but you probably want your example to not use our [remote-state.tf](http://remote-state.tf) module. Just refactor the remote state stuff you already wrote to be in the component calling the module rather than in the module itself. (Or just leave and close the PR as is and close it. You have already contributed a lot, for which we are grateful.)

What if we make the module accept any state type? I would use your [remote-state.tf](http://remote-state.tf) but that seems to be using yaml config. I’m not really sure how to use that with the current module as is

Correct, our [remote-state.tf](http://remote-state.tf) gets its configuration from YAML files compatible with atmos. Atmos is how Cloud Posse handles configuration for all its clients, but we do not want our open source Terraform modules to depend on it because we want them to be widely accessible/useful and do not want to force anyone to use atmos. So that puts us in a bit of a bind: the only remote state access configuration we want to support is one we do not want in our open source modules. This is why I suggest you publish your solution as an example, rather than try to add it to the module itself.

@Jeremy G (Cloud Posse) I have refactored the PR and removed the remote state data source together with kubernetes_config_map_v1_data. Instead I used a SSM parameter to remember the previous map_additional_iam_roles. Can you take another look at it? Thanks https://github.com/cloudposse/terraform-aws-eks-cluster/pull/157

This one was interesting… so I just put the command I ran manually as a before step and it worked. I wonder if it’s sudo that made the difference. Anyways, please disregard. Should be working now

Nested module: https://registry.terraform.io/modules/cloudposse/iam-system-user/aws/0.23.2

creating key using kms_key module, using conditional create using count

the alias appears to be the problem

if I take the alias away and try to use terraform aws_kms_alias then it fails

if I leave alias in CloudPosse module then I get a plan but since I am using conditional, I have to create multiple aliases

well my understanding is that alias is a required input

but the docs say no

The variable definition is:

variable "after_cluster_joining_userdata" {
  type        = list(string)
  default     = []
  description = "Additional `bash` commands to execute on each worker node after joining the EKS cluster (after executing the `bootstrap.sh` script). For more info, see <https://kubedex.com/90-days-of-aws-eks-in-production>"
  validation {
    condition = (
      length(var.after_cluster_joining_userdata) < 2
    )
    error_message = "You may not specify more than one `after_cluster_joining_userdata`."
  }
}

It clearly says additional commands (in plural)

https://github.com/cloudposse/terraform-aws-eks-node-group/issues/123

I’ve created a PR with what I think it could fix this https://github.com/cloudposse/terraform-aws-eks-node-group/pull/124

@Julio Chana Sorry if this is confusing, but it follows the pattern that optional data is provided in a list of zero or one items. The userdata can be a multi-line string:

  after_cluster_joining_userdata  = [<<-EOT
    # After joining the cluster, execute a couple of commands
    echo foo
    echo bar
    EOT
  ]

I would prefer you use the input this way rather than extend the options for the input because we use this zero or one pattern a lot and adding exceptions, even helpful ones, seems in the long run to add more confusion than it does remove obstacles, especially across a library of modules as big as Cloud Posse’s.

OK?

Hey @Ishan Sharma Atlantis per-se can’t be integrated with Tfsec.

Atlantis basically listens for Gitlab/Github Terraform pull requests webhooks, runs and comments pull request with output of plan .

Tfsec is easily integrated into Github Actions workflow, but it can be also easily integrated into any other CI/CD systems as separate stage.

Thank you @Alan Kis for your answer. In the last few hours I had also came to similar conclusion. And used a Github action tfsec-pr-commenter-action however I have encountered another issue that this action does not write comments on the PR for the existing terraform code [ if not changed] and printing the error ; fe

Vault does not have purge protection enabled. .... not writing as not part of the current PR

There seems to be couple of issues opened on the topic as well but not really a solution ref : https://github.com/aquasecurity/tfsec-pr-commenter-action/issues/46

Have you encountered something similar ?

Atlantis can in fact run tfsec

you can run scripts or anything on an Atlantis workflow

you can customize your workflow create a custom image with Atlantis and tfsec and you just modify your plan command to do so

Atlantis integrates with infracost, terragrunt in the same way

In fact, that’s correct @jose.amengual . Kinda liked approach to put it in specific stage.

@Ishan Sharma Yes, the issue that you have mentioned is well known, I used different action, I’ll have a look and update here.

The easy solution is to cut a new docker container of atlantis to include tfsec and any other tools. Then you can add a custom workflow

Did you check the tf expression for count on data source tls_certificate.cluster, maybe there is a clue there, why the list of certs is empty.

Although it could also be the certificates field of one of the tls_certificate.cluster certs that is an empty list.

Of course it’s going to be empty @OliverS as it’s while attempting to stand up a brand new EKS cluster that doesn’t exist yet. Which is the whole point… stand it up and and enable OIDC provider

I’m having the same issue @Jeremy (UnderGrid Network Services). Were you able to solve this?

@Sol no I hadn’t resolved it. I did note that if I set it to false I can execute a plan but I’d rather not have to do 2 deploys if I can help it.

I am running the example made by Cloud Posse without modifying anything at all, and got the same error. I’m not sure what’s going on. Maybe someone from the Cloud Posse team knows? Invoking @Erik Osterman (Cloud Posse) as my PoC

I’m using the 1.2.5 Terraform version, and I’m seeing the same error with the 1.1.0

Yeah I had it w9th 1.1.9 and 1.2.5

@Jeremy G (Cloud Posse) see this?

I wonder what happens if we would just run the tests in CI against main and see if it happens

I’d developed our EKS deployment incrementally and I believe I enabled the OIDC provider after it had been initially deployed. Now I was working to launch a new EKS cluster from scratch using what I’d written and encountered this problem. I know the EKS cluster module had an update but looking at the diff it didn’t show anything I thought would have changed this behavior from what I could see. I’d initially been using Teraform 1.1.9 but I’ve upgraded to 1.2.5.

When I get started working in the morning I’ll go back and double check my existing deployment with Terraform 1.2.5 and the latest EKS Cluster module to ensure it’s still solid. I still haven’t launched the new cluster since the plan was failing. I’ve got some network firewall work being done by someone else in the VPC but that shouldn’t affect this but it should be resolved by tomorrow as well.

examples/complete creates a cluster (even the VPC) from scratch and has oidc_provider_enabled = true and our automated testing should not allow a release without that succeeding.

This has got to be a change in behavior of either Terraform or a Terraform provider. I’m guessing the provider.

Yes, this is a known bug in the TLS provider v4.0.0. Pushing a hot fix to disallow v4 for now.

Thank you @Jeremy G (Cloud Posse) and @Erik Osterman (Cloud Posse)

https://github.com/cloudposse/terraform-aws-eks-cluster/releases/tag/2.3.1

Amazing, thank you again!

Thanks @Jeremy G (Cloud Posse) !!

Okay so the issue was the v4 AWS provider then?

@Jeremy (UnderGrid Network Services)
Okay so the issue was the v4 AWS provider then? Close. The issue was the hashicorp/tls v4 provider. See https://github.com/hashicorp/terraform-provider-tls/issues/244

Ah okay that makes sense. Looks like the provider may have gotten a fix this morning

https://github.com/cloudposse/terraform-aws-eks-cluster/releases/tag/2.3.2

@Dimitris Kargatzis Are you saying you’re trying to change the max allocatable pods via the kubelet configuration via bootstrap.sh?

Have you looked at before_cluster_joining_userdata?

@Matt Gowie Yes this is the case. I tried the bootstrap_additional_options = ["--max_pods=20"] (this) input with no result. Can I use the before_cluster_joining_userdata for specifing the max allocatable pods via the kubelet configuration via bootstrap.sh?

I am also curious to know why the default ‘max allocable pods’ is 8 and the default that AWS proposed for the t3a.large is 35? Ideally we don’t want to specify this value as this is dependent on the node type and node-groups support multiple types e.g. if the node-group creates a medium node the ‘max allocatable pods’ for this node type is 17

@Dimitris Kargatzis not 100% what the deal is.

@RB might know when he comes online — I’ll defer to him so I don’t lead you astray.

It looks like you’re using --max_pods but it seems like the correct flag name is --max-pods

see https://docs.aws.amazon.com/eks/latest/userguide/cni-increase-ip-addresses.html
–use-max-pods false –kubelet-extra-args ‘–max-pods=110’

That input bootstrap_additional_options gets passed into

https://github.com/cloudposse/terraform-aws-eks-node-group/blob/61ac9304b3f4e7383639fdca4712a4580535f461/userdata.tpl#L17

which then uses bootstrap.sh

https://github.com/awslabs/amazon-eks-ami/blob/master/files/bootstrap.sh

I only see the --use-max-pods flag and it defaults to true already

https://github.com/awslabs/amazon-eks-ami/blob/03cc9d7a3eaec8ad145dd73cd7ee21970b4e9d54/files/bootstrap.sh#L19

Thanks for your prompt response @RB, much appreciated! Can I set this value to false?

@RB I just tried the bootstrap_additional_options = ["--max-pods=20"], still the same. The node-groups creation failed with the following error

╷
│ Error: error waiting for EKS Node Group (quine-eks-prod-cluster:test-test-eks-prod-workers-marlin) to create: unexpected state 'CREATE_FAILED', wanted target 'ACTIVE'. last error: 1 error occurred:
│       * i-0e9c62de251df915b: NodeCreationFailure: Instances failed to join the kubernetes cluster
│
│
│
│   with module.cloudposse-eks.module.eks_test_node_group.aws_eks_node_group.cbd[0],
│   on .terraform/modules/cloudposse-eks.eks_test_node_group/main.tf line 185, in resource "aws_eks_node_group" "cbd":
│  185: resource "aws_eks_node_group" "cbd" {

You can see the related module below

module "eks_test_node_group" {
  source  = "cloudposse/eks-node-group/aws"
  version = "0.27.2"

  subnet_ids     = module.subnets.public_subnet_ids
  cluster_name   = module.eks_cluster.eks_cluster_id
  instance_types = ["t3a.small", "t3a.medium", "t3a.large"]
  desired_size   = 1
  min_size       = 1
  max_size       = 2

  environment       = "test"
  namespace         = "test"
  kubernetes_labels = {
    "performance" : "test"
  }

  additional_tag_map = {
    TerraformManaged = true
    Performance      = "test"
  }

  bootstrap_additional_options = ["--max-pods=20"]

  # Auto-scaling discovery
  cluster_autoscaler_enabled = var.cluster_autoscaler_enabled

  # Prevent downtime - create the new node group before destroying the old one
  create_before_destroy = true

  # Prevent the node groups from being created before the Kubernetes aws-auth ConfigMap
  module_depends_on = module.eks_cluster.kubernetes_config_map_id

  context = module.this.context
}

This may be out of my expertise. I have seen something like this before but not in regarding to maximum pods per instance type. I will defer to @Jeremy G (Cloud Posse)

The error “Instances failed to join the kubernetes cluster” can have many causes. You would need to dig into the logs to figure out what exactly the problem is.

--max-pods is not an argument to bootstrap.sh. When --use-max-pods is true, bootstrap.sh will set --max-pods on in the Kubelet config based on the value in /etc/eks/eni-max-pods.txt.

I think what you want to be doing is setting:

bootstrap_additional_options = ["--use-max-pods=false"]
kubelet_additional_options = ["--max-pods=20"]

Thanks @Jeremy (UnderGrid Network Services) for your input. However, I am not still able to create an EKS node-group using the bootstrap_additional_options and kubelet_additional_options inputs. See my findings below • An EKS node-group (AMI release version 1.22.9-20220629) is created successfully without these inputs
• When I specify these inputs the cloudposse/eks-node-group/aws module tries to create a new EKS node-group (AMI release version ami-0fd784d3523cda0fa) and fails after ≈20 minutes with the following error message

╷
│ Error: error waiting for EKS Node Group (quine-eks-prod-cluster:prod-prod-eks-prod-workers-bird) to create: unexpected state 'CREATE_FAILED', wanted target 'ACTIVE'. last error: 1 error occurred:
│       * i-00fb87d7894617347: NodeCreationFailure: Instances failed to join the kubernetes cluster
│
│
│
│   with module.cloudposse-eks.module.eks_test_node_group.aws_eks_node_group.cbd[0],
│   on .terraform/modules/cloudposse-eks.eks_test_node_group/main.tf line 185, in resource "aws_eks_node_group" "cbd":
│  185: resource "aws_eks_node_group" "cbd" {
│

I suggest looking at the instance logs to find out what errors are being generated. The default setting for a t3a.large is 35, so I don’t know why you are seeing 8 to begin with, and I suspect the problem is that whatever is causing you to see 8 is causing the setting of 20 to create a problem setting up the instance networking.

As a test, try setting --max-pods=6 and see if that works.

@Jeremy (UnderGrid Network Services) Same issue with --max-pods=6. I am looking at the instance logs now. But, I am still wondering why a different AMI release version is created when I specify these inputs.

we see this regression happening in our infra - we also discovered that in eks 1.20 or early versions of 1.21 works but anything from late minor versions of 1.21 and 1.22+ is broken.

Hi again @Jeremy (UnderGrid Network Services) @Matt Gowie @RB.

I have created a new EKS node-group using the AWS console, same AMI release version and node type. The pods capacity is 35 as expected.

I have also tried exact the same Terraform implementation / config (using the cloudposse/eks-cluster/aws and cloudposse/eks-node-group/aws Terraform modules) with Kubernetes versions 1.21 and 1.20. Same EKS node-groups with t3a.large node types were created. The pods capacity for the 1.21 Kubernetes version were again 8 and for 1.20 was 35 as the default one proposed by AWS. *I have not defined any additional bootstrap or kubelet option.

Let me if you are aware of this issue otherwise I will create a new issue on GitHub.

If you can identify the solution we might be able to implement it relatively quickly, but this is not something we are going to be able to investigate to find the root cause anytime soon. Most likely it is some kind of change due to the AMI or VPC CNI or new/changed flags in Kubernetes 1.21.

it would be great to note this in the project, as it’s completely broken.

Auto-scaling does not work and also results in severe underutilisation of the cluster leading to massive cost increases.

@andylamp When you say “it’s completely broken”, do you mean you can no longer create EKS clusters with it?

no, we can - but using this in production is insane.

for example for a large node which costs a lot of money - only 8 pods can be used.

if we are talking about using a “toy” example, for sure - it is not broken. You can indeed provision eks clusters. But can they work in a production environment? Definitely not.

Please check that you are using the required version of the required add-ons. See https://docs.aws.amazon.com/eks/latest/userguide/managing-vpc-cni.html

this resolution came from contacting AWS support about it.

I was not sure what was happening and we escalated to eks support about it.

@andylamp
this resolution came from contacting AWS support about it. What resolution are you referring to?

that the tf module was suspect, we provisioned through regular eks aws modules and both pod capacity per node type worked as well as autoscaling.

not sure what exactly is happening and is wrong but the behaviour is very easy to replicate.

try to provision a cluster with 1.21 or 1.22 using clouseposse modules using large nodes (or greater) and see the node capacities that are reported after provision.

in all instances are 8

(and auto-scaling does not work)

we had to tweak the console settings in order to enable so we could debug what was happening.

What did your debugging find was the root cause of the problem?

nothing yet - we opted to use default aws modules as this was taking too much time.

same issue happens for me now

╷
│ Error: error waiting for EKS Node Group (ireland-staging-eks-shard1-cluster:ireland-staging-eks-shard1-workers-cardinal) to create: unexpected state 'CREATE_FAILED', wanted target 'ACTIVE'. last error: 1 error occurred:
│       NodeCreationFailure: Instances failed to join the kubernetes cluster
│
│
│
│   with module.eks_node_group.aws_eks_node_group.cbd[0],
│   on .terraform/modules/eks_node_group/main.tf line 195, in resource "aws_eks_node_group" "cbd":
│  195: resource "aws_eks_node_group" "cbd" {
│

which logs I can check on the ec2? I can login to the ec2, no idea why it fails to join. using plain modules, both the cluster and the node group, with common settings nothing special might it help to specify a different AMI for the launch template somehow?

@Dmitry Shmakov I’ve just had a nearly 2 hour AWS support chat late last night because I had some nodes failing to join the cluster. Can you check the DHCP options for the VPC you’re attempting to place the cluster in?

hmm, it shows this

it’s a new VPC that gets created and peered with our internal one i use for devops access to other VPCs. the peering works so terraform keeps running and can work with the cluster (i’m applying some helm charts on the 2nd pass from another folder and it kinda works just to check i have access to api, but nodes never start so first pass of the infra fails at the nodes group step)

Okay so it isn’t the same issue I was encountering… You already have domain-name-servers set to AmazonProvidedDNS. The VPC I was trying to deploy into had a custom domain-name and domain-name-servers pointing to a Windows AD DC and nodes were unable to join until I setup domain-name-servers to use the AWS provided.

i see, an interesting direction though, I just noticed that this new VPC has no DNS Hostnames enabled maybe that’s a reason, if a hostname of a node that tries to join from boot script is not what the cluster expects? will try that fix

oh yeah.. you have to have DNS hostnames and DNS resolution both enabled… all 3 of those settings are pre-reqs I was told

Glad that helped @Dimitris Kargatzis

Thank you @Jeremy (UnderGrid Network Services)

Hey here I’m pretty new to eks and I’m also facing the max-pod limitation that is below the node’s native pod limit. Although I’ve tried to follow the discussion, I’m currently not able to draw a conclusion.

As far as I understood, the node’s max pod value should default to the instance type’s native pod limit, but for some networking reasons it could not be applied. Is that correct?

If so, I’m wondering what in my terraform setup I need to check in order to not run into this issue.

Hello @Ben! I am not sure if this is related with networking issues. But, yes the node’s max pod capacity should be the same with the instance type’s pod capacity. I surpassed this issue by replacing the module provided by Cloudposse with related Terraform resources provided by AWS. Let me know if you are interested in this solution.

Hi @Dimitris Kargatzis, thank you! I already got it solved: https://sweetops.slack.com/archives/CCT1E7JJY/p1677056510367349?thread_ts=1676993089.822849&cid=CCT1E7JJY The main issue was, that I once did have the right config in terraform, but applying it did not fix the issue, as the old pod limit value was still baked in in the node group’s launch template. So I needed to trigger a launch template update, which seems kind of a workaround, but finally helped.

@Eric Edgar It’s possible this isn’t supported by the module as the community hasn’t run into this use-case yet.

Do you know how you would implement this if you were developing your own Terraform module around Dynamo? Can you fork the existing module and add support for what you’re looking for?

FYI — I don’t know much about Dynamo or this specific functionality. I’m just answering your question given you’re looking for something that likely isn’t there.

I am not sure how I would tackle it yet myself. as a workaround we would need to create a provider for each region and then add the autoscaling rule to that provider based on a data lookup.. crossing the regions is tricky in a module I would assume.

are there other modules that perform actions that cross regions?

Ah if it’s not a native Dynamo thing to enable via the existing provider then it’s not likely we would support it. Cloud Posse module usually stick to one region unless it’s truly crucial to the happy path implementation of that module. What you’re describing is likely non-happy path, but more advanced use-case.

I would suggest either updating your root module to handle your case OR you could form and do your changes inside the module and then maintain it there.

hrmm yeah I guess we might need to wrap the module based on that thought..

Because of how Terraform providers work, it’s not possible to define dynamic providers at runtime. So to create multi-region infrastructure, you generally want to use single-region modules and explicitly instantiate them across all required regions:

provider "aws" { region = "us-east-1" }
provider "aws" { region = "eu-west-1", alias = "ew1" }
provider "aws" { region = "ap-southeast-2", alias = "ase2" }

module "dynamodb_primary" {
  # ...
}
module "dynamodb_replica_ew1" {
  providers = { aws = aws.ew1 }
  source_table = module.dynamodb_primary.table_arn
  # ...
}
module "dynamodb_replica_as2" {
  providers = { aws = aws.ase2 }
  source_table = module.dynamodb_primary.table_arn
  # ...
}

(or something. I don’t know what the module’s interface/dynamodb’s API for global replication looks like)

we have a yaml configuration that is deep merged by atmos to create tfvars, generate a backend, select a workspace dynamically, and run terraform commands

https://github.com/cloudposse/atmos

we use root modules that we call components to create infrastructure. we upstream our components here.

https://github.com/cloudposse/terraform-aws-components

you can learn more about this setup here

https://atmos.tools

here is an example of how we set this up with customers

https://github.com/cloudposse/atmos/tree/master/examples/complete

https://github.com/cloudposse/terraform-provider-utils

This is what does the YAML deep merging

So basically, we have a CLI, and a provider

(we will move moving the functionality into an atmos provider, but haven’t gotten back to it)

definitely interesting as there is significant overlap with how I’ve been doing things but custom for each project

Not enough docs though, so i’d have to experiment, I’ll see… is there perhaps a recording of a demo somewhere?

I’m particularly interested in the deepmerge of yaml configuration files to generate tfvars files, BUT ALSO the generation of the corresponding config schema in variables.tf. Terraform does not make that easy.

(besides data external)

There is a terraform provider but it only has a data source to read from remote state

https://registry.terraform.io/providers/hashicorp/terraform/latest/docs

you mentioned the data external provider and that may be the best way to get the terraform version

what is the problem you’re trying to solve ?

You can set the allowed terraform versions to run a configuration. That might do what you need

This is a CLI hack but it works:

Code:

variable "tf_version" {
  type    = string
  default = "v1.2.6"
}

output "tf_version" {
  value = var.tf_version
}

CLI:

tf apply -auto-approve -var="tf_version=$(terraform -version | head -1 | awk '/Terraform/{ print $2 }')"

Output:

tf_version = "v1.2.6"

Switch to a different version (ie, using tfswitch ) and rerun:

10:43 $ tf apply -auto-approve -var="tf_version=$(terraform -version | head -1 | awk '/Terraform/{ print $2 }')"

Changes to Outputs:
  ~ tf_version = "v1.2.6" -> "v1.1.8"

You can apply this plan to save these new output values to the Terraform state, without changing any real
infrastructure.

Apply complete! Resources: 0 added, 0 changed, 0 destroyed.

Outputs:

tf_version = "v1.1.8"

I have the same question for modules… We had a simple use case: To label all resources with the version of the module that last modified them. We thought we had a (domain specific) solution using the git provider to reflect the repo that was pulled by terraform, but we found it to be unreliable because of some implementation details in Terraform core. Anyone ever come across this?

Simple answer is to set it as an input variable

But if you want a module to tag its own resources with its version, you can hardcode the version into the module

@Robert Jordan you might be able to use something like Yor from Bridgecrew https://github.com/bridgecrewio/yor

I guess I forgot to mention the automatic tagging and release part of the problem… We did look into Yor, but it didn’t quite do what we needed. I think we actually could have done it by running a release step that does as @Alex Jurkiewicz suggests and hardcode it automatically. ah well… next time. Thanks for the suggestions!

Try pinning the tls provider too

Id pin it to ~> 3

https://registry.terraform.io/providers/hashicorp/tls/latest/docs

Cc @Nishant Kumar

Why do you want to write a module?

a) each framework will be addressing a different plan as each plan has diff setting like backup frequency and backup duration

b) the report looks at framework and stores a copy in csv/json format but has the capability to report on various frameworks

I have written terraform code for frameworks but its like 12 different frameworks for 12 different backup plans

also, I am not getting anywhere with backup_report_plan

if there’s any other way to get around it, I am happy to go down that road @Alex Jurkiewicz

@dan callum check out : https://github.com/cloudposse/terraform-aws-backup

thanks @Matt Gowie I’ve looked at that, that is for backup

I am looking for backup framework and backup reports

You might need to be more specific about the technical problem you are having. I and others probably don’t have experience with backup framework, but we can advise on Terraform’s language features

i think I got the framework part alright, it is not at cloudposse level but it does what I want

the reporting is what I need some help with

I have to word this better… for getting help

Not sure many of us know what it supports or doesn’t support. You’ll have to dig into the code + variables to figure that out.

If doesn’t include support for what you’re looking for then be sure to add support on a fork and put it up on PR!

Uploading modules to s3. App ppl can download the modules but not upload controlled by iam policies?

in this case, some app teams do source their custom modules directly from Github on-prem. some do source directly from third party sources e.g Hashi public registry

we just migrated from multi-org TFE to single org TFC.

some app folks are asking for easy way to publish modules without needing to consult DevOps team

@olad I guess you should look at all the rest of the TACOS out there that might be a better fit for your needs - this blog post might help you as well - https://medium.com/@elliotgraebert/four-great-alternatives-to-hashicorps-terraform-cloud-6e0a3a0a5482

It was also talked about in the latest Office hours - https://youtu.be/gWbBF-bflPw?t=925

• Disclaimer - I am the CTO and co-founder of env0

@olad something we’ve specifically built is a first class module repository, since it is built on top of authress it has really flexible permissions and role management policies. If you want a link or a demo, let me know.

looks like only org owner can publish and delete modules. unfortunately for us we only have a single org for all app teams. so devops admins will always be needed to publish modules to the registry.

@olad we are actually working on a more fined grain RBAC to enable to give users the specific roles to publish and delete modules from the private module registry.

easy peasy

module hello_world {
  source = "./modules/hello"

  for_each = is_this_true ? local.the_values : []
}

basically pass an empty set to the module if your condition is not meet, otherwise pass the value that needs to be iterated.
